JK-1500E SERIES

JACK JK-1500E Interlock Machine

The JK-1500E series is a universal 3-needle interlocking arm sewing machine that allows for easy sewing of all garment elements that are difficult to sew on traditional sewing machines.

The machine is suitable for both thick and thin materials. The standard machine arm length is 380 mm, with an optional 450 mm length available. An energy-saving servo drive is installed in the machine head. Machines are available with or without automatic thread trimming. Automatic thread trimming using a stepper motor ensures fast and precise cutting and reduces noise levels.

Technical parameters:

  • sewing speed 4000 stitches/min
  • presser foot lifting height: 8 mm
  • stitch length: 1.2 – 4.5 mm
  • number of needles: 3
  • number of needles: 3
  • needles: UY128GAS
Leaflet JACK JK-1500E

Automation

Automatic thread cutting with a stepper motor ensures fast and precise cutting and reduces noise levels.

Automatic presser foot lift

The new system is perfect for sewing both ultra-thin stockings and thicker sportswear.

Stitch adjustment

3-needle, 5-thread ladder stitch sewing. The machine can be adapted to various technological needs.

Large work space

Arm length 380 mm. Optional arm extension up to 450 mm available.
